Concrete Reinforcing Mesh - Welded Ribbed Steel Rebar Fabric Reinforcement

Welded mesh reinforcement is made from metal rods with 3 to 40 mm diameter. These metal rods are perpendicular bonded by spot welding. Concrete reinforcing mesh used in residential, industrial and road construction, such as concrete footpaths and industrial and commercial ground slabs, precast panel construction and residential slabs and footings.

Our reinforcing mesh wire is ribbed steel rod, which creates improves bonding to concrete, minimizes any concrete cracking that may occur as a result of concrete shrinkage.

Smooth steel reinforcing mesh also can be manufactured according customers special requirement.

Concrete reinforcing mesh welded details.
CRM-1: Concrete reinforcing mesh from deformed steel welded details.
Many sheets of black concrete reinforcing square mesh.
CRM-2: Concrete reinforcing square mesh in 7.6 mm steel wire with 100 mm mesh size.

Specification of concrete reinforcing mesh:

  • Type: Concrete mesh heavy type (diameter of rods above 12 mm) and light type (diameter of rebar rods from 3 mm up to 10 mm).
  • Material: stainless steel rebar rods, galvanized steel rods (with its excellent resistance to corrosion, galvanized reinforcing mesh can be successfully used in wet conditions).
  • Mesh shape: rectangular or square.
  • Distance between rods 100, 200, 300, 400 and 500 mm.
  • Mesh sheet width: 650 mm - 3800 mm.
  • Mesh sheet length: 850 mm, 6 m, 9 m, 12 m.
  • Standard reinforcing mesh sizes are 6.0 m × 2.4 m. And 4.80 m × 2.4 m, 3.6 m × 2 m, 2 m × 4 m also offered.
Table 1: Square Rib Reinforcing Mesh 6.0 m × 2.4 m Common Dimension
Items Longitudinal Wire (mm) Edge Wire (mm) Cross wire (mm) Sheet Weight (kg)
SRM7676 7.60@100 7.60@100 7.60@100 105
SRM9567 9.50@200 6.75@100 9.50@200 80
SRM8560 8.55@200 6.00@100 8.55@200 65
SRM7660 7.60@200 6.00@100 7.60@200 52
SRM6747 6.75@200 4.75@100 6.75@200 40
SRM6047 6.00@200 4.75@100 6.00@200 33
SRM4740 4.75@200 4.00@100 4.75@200 21
Table 2: Rectangular Rib Reinforcing Mesh 6.0 m × 2.4 m Common Dimension
Items Longitudinal Wire (mm) Cross Wire (mm) Sheet Weight (kg)
RRM1210 11.90@100 7.6@200 157
RRM1110 10.65@100 7.6@200 131
RRM9510 9.50@100 7.6@200 109
RRM8610 8.55@100 7.6@200 93
RRM7610 7.60@100 7.6@200 79
RRM6810 6.75@100 7.6@200 68
Table 3: Reinforcing Mesh 4.8 m × 2.4 m Common Dimension
Items Longitudinal wire (4.8 m) Cross wire (2.4 m) Weight
Size (mm) Pitch (mm) Area (mm2/m) Size (mm) Pitch (mm) Area (mm2/m) (kg/m2) (kg/sheet)
SQU4810 10 200 393 10 200 393 6.16 70.96
SQU4808 8 200 252 8 200 252 3.95 45.50
SQU4807 7 200 193 7 200 193 3.02 34.79
SQU4806 6 200 142 6 200 142 2.22 25.57
SQU4805 5 200 98 5 200 98 1.54 17.74
RECT4812 12 100 1131 8 200 252 10.90 125.57
RECT4810 10 100 785 8 200 252 8.14 93.77
RECT4808 8 100 503 8 200 252 5.93 68.31
RECT4807 7 100 385 7 200 193 4.53 52.19
RECT4806 6 100 283 7 200 193 3.73 42.97
RECT4805 5 100 196 7 200 193 3.05 35.14
RECT4810 10 100 785 6 400 70.8 6.72 77.41
RECT4809 9 100 636 6 400 70.8 5.55 63.94
RECT4808 8 100 503 6 400 49.0 4.51 51.96
RECT4807 7 100 385 6 400 49.0 3.58 41.24
RECT4806 6 100 283 6 400 49.0 2.78 32.03
Table 4: Reinforcing Mesh 3.6 m × 2.0 m Common Dimension
Items Long Wires (3.6 m) Cross Wires (2.0 m) Weight
Size (mm) Pitch (mm) Area (mm2/m) Size (mm) Pitch (mm) Area (mm2/m) (kg/m2) (kg/Sheet)
RM3610 10 200 393 10 200 393 6.16 44.35
RM3608 8 200 252 8 200 252 3.95 28.44
RM3607 7 200 193 7 200 193 3.02 21.74
RM3606 6 200 142 6 200 142 2.22 15.98

Note: The dimension of steel reinforcing mesh in above table is the common use size. If your project need other size, please mail to sales@wnmesh.com to contact our products manger. She will give you full dimension data of our concrete mesh.

Steel reinforcing mesh suitable for use in a variety of applications including:

  • Building. Welded mesh reinforcement is widely used for reinforcement of concrete structures. It increases the strength of formed concrete structures. For this use, welded mesh reinforcement wire diameter is from 10 to 30 mm.
  • Welded reinforcing mesh used for the reinforcement of road surfaces.
  • Reinforcement mesh is applied in everyday life, for the reinforcement of masonry walls, as well as for the manufacture of various fences.
Galvanised concrete reinforcing mesh panels with rectangle mesh opening.
CRM-3: Concrete reinforcing rectangle mesh from 8.55 mm longitudinal wire and 7.6 mm cross wire with 100 mm × 200 mm mesh size.

Inquiry for Our Product

Anping County Wennian Wire Mesh Products Co., Ltd.
E-mail: sales@wnmesh.com

When you contact us, please provide your detail requirements. That will help us give you a valid quotation.

Full Name *
Country Code * + Phone Number *
Your Website
Message *

Need more information, such as, welded rebar concrete mesh price, free quote, installation tips, please E-mail to us

Our shippers will send the goods to you as soon as possible.
